The KeyMaster G3 USA STD

From OBDStar is an intelligent, Android-based programming device designed specifically for immobilizer work on U.S. market vehicles. With a focus on IMMO functionality, OBDII diagnostics, EEPROM/MCU programming, and smart key operations, the USA STD version delivers essential capabilities for locksmiths and automotive technicians — without the added complexity or cost of ECU flashing or cluster calibration.

IMMO:

• Support for Volkswagen MQB key programming with free synchronization code calculation
• Proximity key programming for the latest Toyota models
• All-keys-lost programming for:
  • Nissan Rogue, Sentra, and more
  • Ford vehicles from 2021 onward
• PIN code reading support for Hyundai/Kia ID6A and related systems
• BMW motorcycle OBD key programming for ID8A, ID4D, and ID46 transponders

Package Includes:

• KeyMaster G3 USA STD Main Unit
• OBDII Diagnostic Cable
• Power Supply & USB Cable
• Quick Start Guide
• Carrying Case

OBDSTAR C4-07 (MB-VGS4-0-NAG2)

C4-07 MB-VGS4-0-NAG2 adapter kit is specifically designed for drilling access to the FBS4 7G-Tronic VGS4-0-NAG2 Transmission Control Module (TCM), supports solder-free virginizing of used TCM via JTAG mode, supports personalization (data transfer) via BENCH or OBD mode, achieving the same effect as ECU clone. This eliminates the requirement for automotive electronics technicians to have advanced soldering skills, making it a powerful tool for professionals in the field.

MB-VGS4-0-NAG2 Adapter Kit

1. C4-07-01 Soldering-free board

2. C4-07-02 Custom positioning board

3. W011

4. W020-V1.1

5. 22mm Custom drill head

6. TCM-012 (optional)

7. Converter V2 (optional)

Note:

1. Need to be used with MP001 multifunctional programmer;

2. All of the above accessories are required to perform the function.
If you already have the TCM-012 and Converter V2, you do not need to purchase them again.

Support Functions:

1. Support all vehicles with VGS4-0 NAG2 7G-Tronic TCU of the FBS4/DAS4 generation Mercedes-Benz;

2. Support solder-free virginizing of used TCM via JTAG mode;

3. Support personalization (data transfer) via BENCH or OBD mode, achieving the same effect as TCM clone.

 Advanced Functions:

1. Custom positioning board for precise and secure drilling access to the control unit;

2. Used together with the custom drill head and a handheld drill, the TCM can be easily opened with minimal exterior damage;

3. High-precision custom board enabling safe, solder-free read/write operations—ensuring reliable data access and operational safety.

Support Tools

Use with OBDSTAR KeyMaster G3, DC706, etc.

The OBS-TOY-30-V2 is a specialized cable designed for advanced key programming operations on Toyota vehicles. It supports all-key-lost scenarios and password-free programming for 4A and 8A-BA smart key types using the X300 DP PLUS, X300 PRO4, or X300 DP Key Master devices.

This kit contains a set of two cables. A Toyota-30 V2 cable and a CAN Direct cable.

Compatible device:

• OBDSTAR X300 DP Plus full
• OBDSTAR X300 Pro4 full
• OBDSTAR Key Master DP Plus
• OBDSTAR Key Master 5

Functions and Vehicle List

• 1. 2019- COROLLA 4A proximity key programming (free pincode);
• 2. 2021- COROLLA CROSS 4A proximity key programming (free pincode);
• 3. 2021- COROLLA CROSS HV 4A proximity key programming (free pincode);
• 4. 2021- COROLLA SPORT 4A proximity key programming (free pincode);
• 5. 2021- COROLLA SPORT HV 4A proximity key programming (free pincode);
• 6. 2021- COROLLA TOURING 4A proximity key programming (free pincode);
• 7. 2021- COROLLA TOURING HV 4A proximity key programming (free pincode);
• 8. 2021- COROLLA HV 4A proximity key programming (free pincode);
• 9. 2019- LEVIN 4A proximity key programming (free pincode);
• 10. 2021- LEVIN HV 4A proximity key programming (free pincode);
• 11. 2021- ALLION 4A proximity key programming (free pincode);
• 12. 2021- LIVIN 4A proximity key programming (free pincode).
• 13. 2018- TOYOTA CAMRY proximity(8A-A9) key programming (free pincode)
• 14. 2018- TOYOTA C-HR proximity(8A-A9) key programming (free pincode)
• 15. 2018- TOYOTA IZOA proximity(8A-A9) key programming (free pincode)
• 16. 2018- LEXUS RX450H proximity(8A-A9) key programming (free pincode)
• 17. 2018- TOYOTA HIGHLANDER HV 8A-AA proximity add keys & all keys lost (free pincode)
• 18. 2018- TOYOTA RAV4 8A-AA proximity add keys & all keys lost(free pincode)
• 19. 2018- TOYOTA RAV4 HV 8A-AA proximity add keys & all keys lost (free pincode)
• 20. 2018- TOYOTA AVALON 8A-AA proximity add keys & all keys lost (free pincode)
• 21. 2018- TOYOTA CROWN KLUGER HV 8A-AA proximity add keys & all keys lost (free pincode)
• 22. 2018- LEXUS ES 8A-AA proximity add keys & all keys lost (free pincode)
• 23. 2018- LEXUS UX 8A-AA proximity add keys & all keys lost (free pincode)
• 24. 2018- LEXUS RX 8A-AA proximity add keys & all keys lost (free pincode)

Sep. 2022 New Update Models:

Toyota
Add 2018- 8A AA Proximity Add key and all keys lost free pin code
Wildlander
Avalon
Rav4
Crown Kluger HV
RAV4 HV

Lexus
Add 2018- 8A AA Proximity Add key and all keys lost free pin code
ES
RX
UX

NOTE:
1. All keys lost requires Key SIM emulator as well.

2.  Smart ecu plug has changed on the 2023. The CAN DIRECT cable and the online calculations are working spot on, no issue 2019 to 2022 on all (A9 A9 and AA AA) (BA BA is the newest which needs 30-PIN cable).
On the plug itself only the power 12v changes.. terminal 3 is for Corolla only, and 4 is for RAV4, Avalon, 4runner, Highlander.

New Update on Nov. 24, 2022

Supports over 90% TOYOTA/ LEXUS vehicles proximity key programming(all keys lost);
Supports vehicles with gateway read smart key ECU IMMO data by OBD (world first released, no need any adapters).

1. Add 2018- proximity(8A-A8) all keys lost(free pincode) for below models:
TOYOTA CROWN
TOYOTA LAND CRUISER
TOYOTA HIGHLANDER(petrol)
TOYOTA PRADO

2. Add 2018- proximity(8A-A9) all keys lost(free pincode, smart key ECU with 24 pin) for below models:
TOYOTA ALPHARD
TOYOTA VELLFIRE

3 .Add proximity(8A-A9) key programming(free pincode, smart key ECU with 27 pin)
4 .Add proximity(8A-AA) key programming(free pincode, smart key ECU with 27 pin)
5 .Add proximity(4A) key programming(free pincode, smart key ECU with 27 pin)
6 .Add read smart key ECU IMMO data by OBD for below models(more models in testing):
TOYOTA ALPHARO
TOYOTA CAMRY
TOYOTA C-HR
TOYOTA CROWN
TOYOTA HIGHLANDER
TOYOTA IZOA
TOYOTA LAND CRUISER
TOYOTA LC200
TOYOTA PRADO
TOYOTA PRIUS
TOYOTA RAV4
TOYOTA VELLFIRE
LEXUS LC
LEXUS LC570
LEXUS RX series
LEXUS RX450H

OBDSTAR DC706 ECU Tool Full Version

Attention:
Does not clone VAG DQ250 before year 2008.
Please register the device before using.

Instructions for registration.

Distributor code is 0086A002.

OBDSTAR DC706 ECU tool is designed for vehicle ECM, TCM and body/other system for ECU programming.  It can read ECU info, R/W Eeprom/Dflash/Pflash/MAP, reset ECU(Virgin), calibrate mileage, read IMMO PIN code, ECU recovery and so on. It's all by OBD or BENCH mode and makes ECU cloning easy.

OBDSTAR DC706 Functions

ECU Clone/ All by OBD or Bench
ECM clone for cars(Bosch, Continental, Delphi, Denso, Magneti Marelli, Siemens...)
ECM clone for motorcycles(Bosch, Delphi, EFI...)
TCM clone(Ac Delco, Bosch, Continental, Getrag, GM, Kefico, Siemens, Temic, ZF...)
Body/Other clone(FCA, FIAT, FORD, GM/OPEL, LAND ROVER/JAGUAR, PSA, SMART, VOLVO...)

Supported ECU Manufacturers

    ALPS
    Autoliv
    Bosch
    Continental
    Delphi
    Denso
    Johnson Controls
    Lear
    Magneti Marelli
    Siemens
    Temic
    Valeo

Supported Brands

Car:

 ASTON MARTIN
    BMW
    FAW
    FCA(ALFA ROMEO, CHRYSLER, DODGE, FIAT...)
    FORD/LINCOLN
    GM/OPEL
    HYUNDAI/KIA
    LAND ROVER/JAGUAR
    LUXGEN
    MASERATI
    MAZDA
    MITSUBISHI
    NISSAN
    OPEL
    PSA
    SMART
    SUBARU
    SUZUKI
    VOLVO
    VW/AUDI/SEAT/SKODA


Motorcycle:

    APRILIA
    BRP
    CFMOTO
    DERBI
    GILERA
    GUZZI
    PEUGEOT
    PIAGGIO
    QJBENELLI
    VESPA


Advanced Functions

1. R/W eeprom/dflash/pflash/Map, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery...
2. Support 200+ ECM types(Partial functions require P003 adapter.)
3. Support dozens of TCM types
4. Support 100+ body/other ECU types(AIRBAG, BCM, BSI, CEM, DDM/PDM, DIM, EPS, KeyLess(RFHUB/RFHM), KVM, RFA, SAM...)
5. Support VW DQXXX (TCM) calibrate mileage
6. Support motorcycle Delphi MT05, MT05.2, MT05.3 ECU clone
7. Support motorcycle BRP ME17.8.5 ECU clone (works with P003 adapter.)
8. Support Piaggio series engine ECU clone(such as MIU G4 (M4G1))
9. Support intelligent search by brand, model, part No., ECU manufacturer, MCU controller type
10. Support automatic identification
11. Strong help data files
12. All by OBD or Bench mode

Attention:

If you need YANWEN express shipping or other shipping methods like UPS, TNT, FedEx and so on, or you have special needs for your order, such as a declared name and so on, please leave a message on the order to notify us. Otherwise we will send the order as our usual practice.

As different countries have different import policies, sometimes we will change the shipping method based on the counties and goods.

When you receive the parcel, before you sign for acceptance, please check the package first to make sure the product is correct and undamaged.
After Sale Service:

If you have any problems, please do not hesitate to contact us. Please give us your detailed description, or error photo. We will provide the solution or solve it for you by teamviewer. For some special function, you can take the photo or video and then send it to us to check whether you operate it rightly.

OBDSTAR FCA 12+8 Cable for Chrysler Work on X300 DP Plus/X300 PRO4/OdoMaster/X200 PRO2

All FCA (FIAT/CHRYSLER/ALFA ROMEO) vehicles after 2018 are equipped with SGW security gateway module to prevent attacks on the vehicle network via the CAN bus. Directly plug in the OBD II-16 connector cannot communicate with the vehicles because SGW security gateway module can block the access to the vehicle's OBD2 port from non-original diagnoses. To solve this problem, you can connect to the 12PIN and 8PIN connections on the car via this FCA 12 + 8  cable to get normal communication with the car.

Product Function:

Vehicle Coverage:


1. Supports 46, 4D data collection;
2. Supports PORSCHE(2005-2010) 46 Pincode decryption;
3. Supports HYUNDAI/KIA 46 Pincode decryption;
4. Supports TOYOTA DSTAES(8A-H) Blade key simulation;
5. Supports SUBARU DSTAES(8A-H) Blade key simulation;
6. Supports TOYOTA DST40(94/D4) Smart key simulation;
7. Supports TOYOTA DST80(98) Smart key simulation;
8. Supports SUBARU DST80(F1/78) Smart key simulation;
9. Supports TOYOTA DSTAES(8A-88/8A-A8) Smart key simulation(all year models);
10. Supports TOYOTA DSTAES(8A-A9) Smart key simulation(all year models);
11. Supports TOYOTA DSTAES(8A-39) Smart key simulation;
12. Supports TOYOTA DSTAES(8A-AA) Smart key simulation(all year models);
13. Supports TOYOTA 4A Smart key simulation;
More features are under development...

OBDSTAR P003+ Kit Supported ECU List:

Supports ECU including BOSCH EDC17U01(TC1766), MED17.5(TC1766), MED17.5.1(TC1766), MED17.5.20(TC1766), MED17.5.5(TC1766), MED17.5.5 HW2(TC1766), EDC17C46(TC1767), ME17.5.6(TC1767), ME17.5.20(TC1767), MED17.5.2(TC1767), MED17.5.5(TC1767), MED17.5.5 HW2(TC1767), MED17.5.21(TC1782), MED17.5.25(TC1782), EDC17C54(TC1797), EDC17C64(TC1797), EDC17CP44(TC1797), EDC17CP44 MS(TC1797), ME17.1.1(TC1797), ME17.1.6(TC1797), MED17.1.1(TC1797), MED17.1.1 MS(TC1797), MED17.1.6(TC1797), MED17.4.4(TC1793), MD1CS018(Euro 6/TC298TP), MG1CS042(Euro 6/TC298TP), MG1CS003(Euro 6/TC298TP) etc.

1. Continental PCR2.1(TC1796)

2010-2014 Audi A1 (8X) 1.6L Diesel

2009-2012 Audi A3 (8P) 1.6L Diesel

2009-2013 Seat Altea 1.6L Diesel

2010-2016 Seat Ibiza IV (6J) 1.6L Diesel

2010-2012 Seat Leon II 1.6L Diesel

2014 Seat Toledo (KG) 1.6L Diesel

2010-2013 Skoda Octavia II (1Z) 1.6L Diesel

2010-2013 Skoda Fabia II (5J) 1.6L Diesel

2010-2011 Skoda Roomster (5J) 1.6L Diesel

2013-2014 Skoda Rapid (NH) 1.6L Diesel

2011-2013 Skoda Superb (3T) 1.6L Diesel

2012/2015 Skoda Yeti (5L) 1.6L Diesel

2010-2015 VW Caddy (2K) 1.6L Diesel

2009-2013 VW Golf VI 1.6L Diesel

2010-2013 VW Golf Plus 1.6L Diesel

2011-2014 VW New Beetle (9C) 1.6L Diesel

2011 VW Passat (B7) 1.6L Diesel

2009-2014 VW Polo V 1.6L Diesel

2010-2015 VW Touran (1T) 1.6L Diesel

2. Bosch MED17.4.4(TC1793)

Citroen C3 Mk2

Citroen C4 Gran Picasso

Citroen C4 MK2

Citroen C5 (RD/TD)

Citroen C6

DS DS3

DS DS5

DS DS6

Peugeot 2008

Peugeot 208

Peugeot 3008 (P84)

Peugeot 3008 (T84)

Peugeot 308 (T9)

Peugeot 4008

Peugeot 408

Peugeot 508

3. Bosch EDC17C60(TC1793)

Citroen Berlingo

Citroen C-Elysee

Citroen C3 Aircross

Citroen C3 MK2

Citroen C3 Picasso

Citroen C4 Cactus

Citroen C4 MK2

Citroen C4 Picasso

Citroen Jumpy

Citroen Spacetourer

DS DS3

DS DS4

DS DS5

Peugeot 2008

Peugeot 208

Peugeot 3008 (P84)

Peugeot 308 (T9)

Peugeot 5008 (T87-P87)

Peugeot 508

Peugeot Expert

Peugeot Ranch/Partner

Peugeot Traveller

Opel/Saturn/Vauxhall Combo E

Opel/Saturn/Vauxhall Crossland X

Opel/Saturn/Vauxhall Grandland X

ToyotaProace

4. Bosch MD1CS018

Mahindra BS-6

5. Bosch MED17XX/EDC17XX

EDC17U01(TC1766)

EDC17C46(TC1767)

EDC17C54(TC1797)

EDC17C64(TC1797)

EDC17CP44(TC1797)

EDC17CP44 MS(TC1797)

MED17.5(TC1766)

MED17.5.1(TC1766)

MED17.5.20(TC1766)

MED17.5.5(TC1766)

MED17.5.5 HW2(TC1766)

MED17.5.2(TC1767)

MED17.5.5(TC1767)

MED17.5.5 HW2(TC1767)

MED17.5.21(TC1782)

MED17.5.25(TC1782)

MED17.1.1(TC1797)

MED17.1.1 MS(TC1797)

MED17.1.6(TC1797)

VW/Skoda/Audi/Seat, Bentley, Lamborghini, Porsche...

6. Bosch ME17XX

ME17.5.6(TC1767)

ME17.5.20(TC1767)

ME17.1.1(TC1797)

ME17.1.6(TC1797)

VW/Audi/Skoda/Seat, Bentley...

OBDSTAR P003 Kit Functions

1. Continental PCR 2.1 reading CS, PinCode, MAC valueP003+ KIT
2. Bosch MED17.4.4 reading eeprom , PinCodeP003+ KIT
3. Bosch EDC17C60 reading eeprom , PinCodeP003+ KIT
4. Bosch MD1CS018 reading eeprom, PinCodeP003+ KIT
5. Bosch MED17XX/EDC17XX reading eeprom, flash, CS, PinCode, MAC value
6. Bosch ME17XX reading & writing eeprom, flash
7. T87A, 6HP reading & writing TCM eeprom, flash

OBDSTAR P005 Adapter Kit

P005 adapter kit includes P005 custom Board and W012 connecting maincable.
lt's used for lMMO function of BMW BDC02, work with X300 classic G3.

Functions:

Support solder-free reading lMMO pincode of BMW BDC02 via BOOT mode, is used for adding keys;
Support solder-free virginizing of used BMW BDCO2 ECU via OBD/BO0T mode.
NOTICE: OBD-mode virginizing requires prior possession of the 32-bit security key. lf the key is unavailable, it must be retrieved by accessing the required data via BOOT mode.

Support Models:

BMW 5 Series:

• G30  2016/2011 - 2020/06
• G31  2017/03 - 2020/06
• G38  2017/03 - 2020/06

BMW 6 Series:

• G32  2017/07 - 2020/06

BMW 7 Series

• G11  2015/07 - 2019/02
• G12  2015/07 - 2019/02

M5 Series:

• F90  2017/11 - 2020/06

X3 Series:

• G08  2018/05 - 2021/08
• F97   2019/04 - 2021/07
• G01  2017/12 - 2021/07

X4 Series:

• G02  2018/04 - 2021/07
• F98  2019/04 - 2021/07

Overview:
The OBDSTAR RH850/V850 Adapter Full Kit is a professional solution for advanced key programming, airbag reset, immobilizer (IMMO) data reading, and pincode retrieval. Designed for automotive locksmiths and ECU specialists, it supports a wide range of RH850 and V850 processor-based systems, including Volkswagen MQB, Ford/Lincoln, Nissan/Renault, FCA, and more.

Key Functions:

1. Volkswagen MQB48-5A Key Programming (Components Removing Free)

• Supports dashboard, ECM, and TCM data reading & IMMO data decryption via BENCH/BOOT
• Compatible with MQB48-5A systems (MQB49-5C in development)
• All Keys Lost (AKL) synchronization code calculation for BLADE & PROXIMITY keys
• ELV IMMO data acquisition via MP001 + RH850/V850 adapter

2. Ford/Lincoln 2021+ Key Programming (Including AKL)

• Supports models such as F-150, Bronco, Navigator, Mustang Mach-E, Explorer, and more

3. Nissan/Renault Key Programming (Including AKL)

• Supports Nissan Sentra, Rogue, Pathfinder, Juke, Qashqai, and more

4. FCA Key Programming (Upcoming Upgrade)

• Fiat 500E, Alfa Romeo Tonale, Jeep Renegade, Dodge Hornet, and others

5. Airbag Reset

• Read, write, and clear crash data for a wide range of brands: Subaru, Toyota, Lexus, Volvo, Mazda, Jaguar, Tesla, Ford, GM, Honda, Hyundai, Kia, VW, and more

Package Includes:

• RH850/V850 Adapter Board (C4-06)
• MCU Boards (C4-06-C01, C4-06-C02)
• W010 & W010A Cables
• Dedicated Decryption Jumpers (5 sets)
• MQB Collector
• ECM-001 Module
• M002 Cable Set
• TCM-MAIN Cable
• Converter V2
• TCM-030 Cable
• Optional TCM-KIT 1 / TCM-001 / TCM-002 / TCM-005 (sold separately)

Supported Tools:

• KeyMaster G3 (Recommended)
• Requires MP001 multifunction programmer for use

OBDSTAR RH850/V850 Adapter

OBDSTAR RH850/V850 Adapter is For Airbag Reset, IMMO Data/Pincode Read(Dashboard, BCM, ELV, etc. )
Need work with X300 G3, P50 together
All data read is unencrypted and can be used on the third party devices.

Functions:

Volkswagen MQB48-5A key programming (components removing free) (MQB49-5C under development)
Ford/Lincoln 2021-key programming (including all keys lost)
Nissan/Renault key programming (including all keys lost)
FCA key programming (upcoming upgrade)
Supports the data reading/writing and repair of the new SRS ECU with encrypted RH850 processor

Package includes:

1pc x C4-06 Adapter
1pc x W010 Cable
1pc x W010A Adapter
1pc x C4-06-C01 Adapter
1pc x C4-06-C02 Adapter
5sets x dedicated decryption jumper

Obdstar Toyota 30-PIN Cable supports 4A and 8A-BA Types Used with X300 DP Plus / X300 Pro4/ Autel IM508 IM608

Product Details:This cable works with X300 DP Plus, X300 PRO4, and X300 DP Key Master devices for all keys lost programming. Supports Toyota 8A and 4A models

Key Programming without pin codes.

Key simulation.

4A Models with TMLF19T
2020+ Toyota Yaris
2020+ Toyota Cross
2022+ Toyota Corolla

8A-BA Models with TMLF19D
2020+ Toyota Sienna
2020+ Toyota Venza
2021+ Toyota Tundra
2021+ Toyota Land Cruiser
2022+ Toyota RAV4

Product Functions:

Support VW IMMO IV NEC24C64 and NEC24C32 AKL.

Without removing IC, soldering PCB and making server data

Read IMMO data by BENCH

The OEM BDC2 BDC3 14-in-1 Adapter Kit is a professional automotive accessory set designed to solve the connection problem for encrypted key programming & matching on modern VAG, Porsche, Audi, and BMW vehicles.

Core Purpose:

It acts as a bridge between your key programmer (e.g., KD-X4, VVDI Key Tool Plus, Autel IM608, etc.) and the vehicle's advanced immobilizer modules, allowing you to read/write encrypted key data without removing the module from the car (on-bench or via OBD).

Key Features:

• No Soldering Required: The kit uses specialized probes and clips to connect to the key's circuit board, preventing damage to the original chip or board.
• Broad Vehicle Support: It covers VAG (VW, Audi, Skoda, Seat) 5C and 5D systems, BMW BDC2/BDC3 (including blade and LCD keys), Porsche, and Rolls-Royce.
• Universal Compatibility: It is designed to work with major diagnostic and key programming tablets such as Autel IM608/IM508, Xhorse VVDI Key Tool Plus, Keydiy KD-X4, and CGDI A2.
• Safety Design: Includes protective sleeves for probes to prevent bending and adjustable screws to ensure a secure connection without crushing the PCB.

Supported Vehicles & Modules:

• for BMW: F/G Chassis with BDC2 / BDC3 / BCP modules (encrypted keys)
• for VAG: MQB platforms with 5C / 5D immo systems
• for Audi: A3 (MQB 5C/5D)
• for Porsche: Models using VAG 5C/5D or related immo systems
